Hioki PQ3198 Power Quality Analyzer
Precision Power Quality Analysis for Critical Electrical Systems
Always authentic product
We only sell 100% authentic products
Fast Shipping
Receive products in amazing time.
Easy returns
Return policy that let you shop at ease
Secure shopping
Your data is always protected
Hioki PQ3198 Power quality analyzers Price in Bangladesh
Hioki PQ3198 Power Quality Analyzers are engineered to deliver comprehensive electrical diagnostics, making Hioki PQ3198 Power quality analyzers Price in Bangladesh a common search among engineers, energy consultants, and maintenance professionals looking for a dependable solution for power quality assessment. Designed for industrial, commercial, and utility environments, this advanced analyzer enables accurate monitoring of electrical systems, helping organizations improve reliability, reduce downtime, and optimize overall power performance.
Comprehensive Electrical Measurement Capabilities
The Hioki PQ3198 provides precise measurement of essential electrical parameters, including voltage, current, frequency, harmonics, power factor, and energy consumption. Its advanced monitoring functions allow engineers to detect electrical disturbances that can affect equipment efficiency and operational stability. Detailed diagnostic information supports effective troubleshooting and informed maintenance decisions.
High Accuracy for Reliable Diagnostics
Accurate electrical analysis is essential for maintaining reliable power systems. The Hioki PQ3198 captures transient events, voltage fluctuations, waveform distortion, and other power quality abnormalities with exceptional precision. This capability allows maintenance teams to identify the root causes of electrical issues quickly, minimizing unnecessary downtime and improving system performance.
Built for Demanding Industrial Environments
Designed for professional field applications, the Hioki PQ3198 features a rugged construction that delivers dependable performance in challenging operating conditions. Its durable design makes it suitable for manufacturing plants, utility substations, commercial facilities, renewable energy installations, and industrial maintenance departments. The robust enclosure ensures reliable operation throughout long term field use.
User Friendly Interface and Efficient Operation
The intuitive operating interface simplifies complex electrical analysis by presenting measurement results in a clear and organized format. Engineers and technicians can efficiently review recorded data, interpret electrical events, and generate meaningful maintenance reports. The streamlined workflow enhances inspection productivity while reducing diagnostic time during field operations.
Supporting Predictive Maintenance and Energy Management
The Hioki PQ3198 plays an important role in predictive maintenance by enabling continuous monitoring of electrical system performance. Early identification of power quality issues allows maintenance teams to resolve problems before they impact critical equipment. This proactive approach improves equipment reliability, enhances energy efficiency, and supports long term operational stability across industrial facilities.
Versatile Applications Across Multiple Industries
The Hioki PQ3198 Power Quality Analyzers are widely used in manufacturing, utility services, commercial infrastructure, renewable energy projects, transportation systems, and facility management. Their versatile analytical capabilities support commissioning, preventive maintenance, energy audits, electrical troubleshooting, and compliance verification in a wide range of professional applications.
Dependable Performance for Professional Engineers
The Hioki PQ3198 combines advanced analytical technology, durable construction, and high measurement accuracy to deliver dependable performance for demanding electrical diagnostics. Its comprehensive monitoring capabilities help organizations maintain reliable electrical infrastructure, improve maintenance efficiency, optimize energy usage, and ensure the long term performance of critical power distribution systems.
Key Features: Hioki PQ3198 POWER QUALITY ANALYZER
- Verify power problems in accordance with the IEC61000-4-30 Class A standard
- High accuracy and continuous gapless recording (V: ±0.1% of nominal voltage, A: ±0.1% rdg. ±0.1% f.s., W: ±0.2% rdg. ±0.1% f.s.)
- Broadband voltage range lets you measure even high-order harmonic components of up to 80 kHz
- Maximum 6000 V peak transient voltage up to 700 kHz
- Measure up to 6000 A AC
- Two systems of power measurement and efficiency calculation for (ch 1, ch 2, ch 3) and ch 4
- Make simple measurements of inverters with 40 to 70 Hz fundamental frequency and max. 20 kHz carrier frequency
- Easily create reports with bundled PQ ONE application software
- Optional GPS BOX for synchronizing multiple devices
Specifications: Hioki PQ3198 POWER QUALITY ANALYZER
| Measurement line type | Single-phase 2-wire, Single-phase 3-wire, Three-phase 3-wire or Three-phase 4-wire plus one extra input channel for voltage, current, power measurement (AC or DC measurement) |
|---|---|
| Voltage ranges | Voltage measurement: 600.00 V rms Transient measurement 6.0000 kV peak |
| Current ranges | 500.00 mA to 5.0000 kA AC (depends on current sensor in use) |
| Power ranges | 300.00 W to 3.0000 MW (determined automatically based on voltage and current range in use) |
| Basic accuracy | Voltage: ±0.1% of nominal voltage Current: ±0.1 % rdg. ±0.1 % f.s. + current sensor accuracy Active power: ±0.2 % rdg. ±0.1 % f.s. + current sensor accuracy |
| Measurement items | 1. Transient voltage : 2 MHz sampling 2. Frequency cycle : Calculated as one cycle, 40 to 70 Hz 3. Voltage (1/2) RMS: one cycle calculation refreshed every half cycle Current (1/2) RMS: half-cycle calculation 4. Voltage swell, Voltage dips, Voltage interruption 5. Inrush current 6. Voltage waveform comparison 7. Instantaneous flicker value: As per IEC61000-4-15 8. 200 ms frequency: Calculated as 10 or 12 cycles,40 to 70 Hz 9. 10 sec frequency: Calculated as the whole-cycle time during the specified 10 s period, 40 to 70 Hz 10. Voltage waveform peak, Current waveform peak 11. Voltage, Current, Active power, Apparent power, Reactive power, Active energy, Reactive energy, Power factor, Displacement power factor, Voltage unbalance factor, Current unbalance factor, and efficiency 12. High-order harmonic component (voltage/ current): 2 kHz to 80 kHz 13. Harmonic/ Harmonic phase angle (voltage/ current), Harmonic power: 0th to 50 th orders 14. Harmonic voltage-current phase angle: 1th to 50 th orders 15. Total harmonic distortion factor (voltage/ current) 16. Inter harmonic (voltage/ current): 0.5 th to 49.5 th order 17. K Factor (multiplication factor) 18. IEC Flicker, Δ V10 Flicker |
| Record | Repeated ON: 1 year, Maximum recording event: 9999 × 366 days (up to 9999 events per day) Repeated off: 35 days, maximum recording event: 9999 events |
| Interfaces | SD/SDHC memory card, LAN (HTTP server function / FTP function), USB2.0 (for communication) |
| Display | 6.5-inch TFT color LCD (640 × 480 dots) |
| Power supply | AC adapter Z1002 (100 V to 240 V AC, 50/60 Hz, rated current 1.7 A), Battery Pack Z1003 (Continuous use: 180 minutes, Charging time: Max. 5 hr 30 m with AC adapter) |
| Dimensions and mass | 300 mm (11.81 in)W × 211 mm (8.31 in)H × 68 mm (2.68 in)D, 2.6 kg (91.7 oz) (including Battery Pack Z1003) |
Includes: Hioki PQ3198 Power quality analyzers
- Hioki PQ3198 POWER QUALITY ANALYZER
